Flow Control 10 GPM 3/4" MPT x FPT - Flo-Trol
SKU: VA-CDY10
Flow Control 10 GPM 3/4" MPT x FPT - Flo-Trol
Flo-Trol automatic flow control valves are designed to give constant flow over a wide pressure range. The internal controlling mechanism has no moving part, consisting only of a flexible orifice that varies with applied pressure maintaining a constant flow rate.
Flow rates are maintained to within ±15% between 15 and 125 PSI (1 to 8.6 bar). The flow rate varies due to manufacturing tolerances and water temperatures. Valve bodies are stainless steel (not chrome or nickel-plated brass) with a Buna-N orifice (NSF/ANSI 61 certified).
Specifications
- Flow Rate - 10 GPM
- Size - ¾"
- Connection Type - MPT x FPT
- Primary Material - Stainless Steel
- Temperature Range - Up to 180°F (82°C)
- Maximum Pressure Rating - 200 PSI
- Product Model - Flomatic Flow Controls
- Hex Size - 1.25 INCH
- Overall Length - 1.50 INCH
Certifications
- No Lead
- NSF / ANSI 372
- NSF / ANSI 61
