Micro Garden Watering Kit
SKU: DIG-G77AS
Micro Garden Watering Kit
The G77AS Drip Irrigation Kit is a complete kit for a garden planted with roses, vines, shrubs, groundcover, flowerbeds or trees. The kit has all the parts needed to start a system from a faucet or a garden hose, and cover up to 150 SF. It can be expanded to cover more than 400 SF using additional drip tubing and PC drip emitters with the same flow rate.
The kit includes all the necessary parts needed to complete the installation.
Features- Use to water roses, shrubs, groundcover, flowerbeds and trees. Ideal for hillsides.
- Complete kit; covers up to 150 sq. ft. (can be easily expanded up to 400 sq. ft.)
- Contains 24 1-GPH PC button drip emitters with 20 1-GPH, two 2-GPH and two 4-GPH drippers.
- Applies water at a very low application rate leading to less surface evaporation from leaves and soil.
- Offers flexibility in irrigation frequency and application rate, minimizing surface compacting and runoff.
- Designed for new and existing landscapes, including difficult terrain such as slopes and oddly shaped areas.
- No special tools or glue are needed.
Product specifications:
- Maximum incoming operating pressure: 100 PSI
- Operating pressure: 25 to 30 PSI (25 PSI pressure regulator included)
- Maximum recommended flow rate: 220 GPH (3.7 GPM)
- Drip poly tubing size: 50' with .600 ID x .700 OD
- Drip micro tubing (Vinyl) size: 50' with .156 ID x .245 OD
- 3/4" FHT x MHT pressure regulator: downstream pressure preset to 25 PSI
- PC drip emitter flow rates: 1, 2 and 4 gallons per hour (GPH)
- Total flow rate for this kit: 32 GPH (.53 GPM)
BOX CONTENTS: | |
qty | description |
---|---|
1 | 3/4" FHT x MHT backflow preventer |
1 | 3/4" FHT x MHT pressure regulator |
1 | 3/4" FHT swivel adapter with 60-mesh screen |
1 | 50' 1/2" poly tubing |
1 | 50' 1/4" micro tubing |
20 | 1 GPH PC drip emitter (black) |
2 | 2 GPH PC drip emitter (green) |
2 | 4 GPH PC drip emitter (red) |
1 | 1/2" compression tee |
2 | 1/4” barb |
2 | 1/4” barbed tee |
2 | 1/4” barbed ball valve |
1 | 1/2" compression coupling |
5 | 1/4” micro tubing holder stake |
1 | Hole punch |
2 | figure “8” hose ends |
2 | goof plugs |
1 | Instruction manual |
