Hydronix 4.5 Gallon Horizontal Pressure Tank
SKU: HYD-AQT4
This item is not eligible for free shipping. Our shipping specialists will contact you with a detailed quote after ordering.
The AQT Hydropneumatic Pressurized Tanks are an idea product for well applications and for applications where you want to minimize pump start-ups every time you use water.
TANK SPECIFICATIONS
- Pre-Charge: 30 PSI (2 bar)
- Max. Working Temp: 200 °F (93 °F)
- Max. Working Pressure: 150 PSI (10 Bar)
- Tank Connection: 1" NPT
- Tank Weight: 8.5 lbs
CONSTRUCTION MATERIALS
- Shell: Cold Rolled Carbon Steel
- Coating: Triple Grade Enamel
- Liner: FDA Grade Polypropylene
- Diaphragm: Heavy-Duty Butyl Rubber
- Connections: 304 Stainless Steel
5 Year Limited Warranty
