Pressure Gauge Liquid Filled 100 PSI, 2" x 1/4" Lower Mount

SKU: PA-PG100LIQ
(0) No Reviews yet
$10.00

In Stock

Pressure Gauge Liquid Filled 100 PSI, 2" x 1/4" Lower Mount


This liquid filled 2" pressure gauge reads from 0 to 100 PSI and has a 1/4" MIPT brass connection from the bottom of a black steel case. Used in applications where vibrations or pressure pulsations occur. General purpose, not for use with oxygen.


*Liquid filled gauges are sealed with a rubber plug to prevent leaking during shipment. Upon installation, the tip of the plug must be cut off to allow the equalization of the internal gauge pressure to the atmospheric pressure. Failure to do so will adversely affect the function of the gauge.
  • Range: 0 to 100 PSI
  • Case: Steel Case, Glycerine filled
  • Accuracy: 2% - 3%
  • Operating Temperature: -4°F to 104°F (-20°C to 40°C)
  • Connection: 1/4" Brass MIPT
  • Window: Polycarbonate
